Product Details:
|
| Usage: | Industrial | Accuracy: | 0.5%FS |
|---|---|---|---|
| Working Voltage: | 100～240V AC/DC | Power Consumption: | ≤6W |
| Working Environment: | 0～50℃ <85%RH | Relay Output: | 3A/250V AC |
| High Light: | Intelligent Temperature Controller 0.5%FS,LED Display Intelligent Temperature Controller |
||
AI108 Series Intelligent Temperature Controller 0.5%FS LED Display one loop output Alarm Heating/cooling controll
1. Features and advantages of AI108 digital temperature controller:
a). Easy operation,economic model.
b). 0.5%FS high-accuracy signal measurement.
c). 2 degree PID arithmetic, have self-tuning fuction.
d). Calculate the best control state automatically.
e). 1 loop alarm function with free setting.
f). Applied to heating control, cooling control, heating-cooling control. Widely used in the heating and cooling control in extruder.
2. Model specification:
3. Technical specification:
Parameter:
| Sample rate | 2 times/per second |
| Relay capacity | AC 250V /3A life of rated load> 100,00 times |
| Power supply | AC/DC 100 ~ 240V ( 85-265V ) |
| Power consumption | <6VA |
| Environment | Temperature of indoor:0 ~ 50°C no condensation; Humidity : < 85%RH,altitude<2000m |
| Storage environment | -10 ~ 60°C,no condersation |
| SSR output | DC 24V pulse voltage,load<30mA |
| Insulation impednce | in put,output, power VS meter cover > 20MQ |
| ESD | IEC/EN61000-4-2 Contact ±4KV/Air ±8KV perf.Criteria B |
| Pulse traip anti-interference | IEC/EN61000-4-4 ±2KV perf.Criteria B |
| Surge immunity | IEC/EN61000-4-5 ±2KV perf.Criteria B |
| Voltage frop & Short interruption immunity | IEC/EN61000-4-29 0% ~ 70% perf.Criteria B |
| Dielectric strength | Signal input & output & power 1500SC1 min.below 60V low voltage DC500V,1min |
| Total weight | About 400g |
| Shell material | The shell and panel framePC/ABS (Flame class UL94V-0) |
| panel material | PET(F150/F200) |
| Power failure memory | 10years,times of writing:! million times |
| Panel protection level | IP65(IEC60529) |
| Safety standard | IEC61010-1 overvoltage categoryH,pollution level 2,level 11( Enhanced insulation ) |
Specification of measuring signal table:
4. Dimension:
5. Connections:
